Maytag PAV2300AWW User Manual download pdf (Page 5)

TOP

No. Part No. Description

Section:

Series Qty

1 35-2026 LID (WHT) (DOOR) 10 1

2 43-0057 ACTUATOR, DOOR SWITCH 10 1

3 25-7438 SCREW Note: SCREW, ACTUATOR 10 1

4 35-2045 PIN, HINGE 10 2

5 25-7893 SCREW Note: SCREW, HINGE PIN 10 2

6 35-2044 HINGE, LID 10 2

7 35-0581 BUMPER, DOOR (LID) Note: BUMPER, LID 10 2

8 35-2063 BUSHING, INSULATOR Note: BUSHING, INSULATOR (LARGE) 10 1

9 21001137 LID SWITCH ASSY.-W/LEADS Note: LID SWITCH ASSY. (W/LEADS) 10 1

10 21001136 SCREW, SWITCH/HOUSING Note: SCREW, LID SWITCH 10 2

11 21001148 SWITCH, LID/DOOR SAFETY SPIN 10 1

12 21001135 HOUSING, LID SWITCH 10 1

13 N 25-7878 CLIP Note: CLIP, LID SWITCH LEVER 10 1

14 21001134 LEVER, LID SWITCH 10 1

15 21001602 TOP, CABINET (WHT) 10 1

16 21001597 DISPENSER, BLEACH 10 1

17 21001592 CORD, POWER 10 1

*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available
