BASE (SERIES 19)

No. Part No. Description

Section:

Series Qty

1 21001110 SPRING, MOTOR PIVOT 19 1

2 21001750 MOTOR (120V 60HZ 2SP) 19 1

3 21001486 SLIDE, FOOT 19 1

4 21001873 PUMP 19 1

5 25-7833 SCREW Note: SCREW 19 2

6 25-7834 WASHER 19 2

7 33-9946 ISOLATOR, MOTOR 19 2

8 35-3570 WASHER, MOTOR PIVOT 19 2

9 21001783 PLATE & SCREW ASSEMBLY 19 1

10 35-3646 ISOLATOR, MOTOR PLATE 19 3

11 25-7831 SPACER Note: SPACER, MOUNTING 19 2

12 21001506 PULLEY, MOTOR-60 HZ 19 1

13 22002721 SHIELD, MOTOR 19 1

14 35-3571 SLIDE, MOTOR PIVOT 19 2

15 33-9967 WASHER, MOTOR ISOLATOR 19 2

16 25-7047 WASHER, FLAT 19 2

17 25-7325 NUT, MOTOR PLATE ASY TO MOTOR 19 2

18 12002102 KIT, SUSPENSION SPRING 19 1

19 21001166 HOOK, SUSPENSION SPRING 19 3

20 21001754 BAR, STABILIZER 19 1

21 35-2046 BRACKET, STABILIZER 19 2

22 35-2052 PIN, STABILIZER 19 2

23 35-3020 FOOT PAD ASSY. (REAR) 19 2

24 25-7828 SCREW, #10 TORQ LIMITING Note: SCREW, BRACKET/BASE 19 6

25 21001893 BASE, WASHER 19 1

26 25-7845 SPEEDNUT Note: SPEEDNUT, MOTOR 19 2

27 21001915 HOSE, TUB TO PUMP 19 1

28 35-3507 FOOT & PAD ASSY 19 2

29 21001161 SNUBBER 19 1

30 21352320 BELT, DRIVE 19 1

31 25-7830 SPACER 19 2

32 25-6068 CLAMP, HOSE Note: CLAMP, TUB 19 2

33 35-2065 PAD, MOTOR PLATE 19 1

*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available
