TUB (PAV2300)

No. Part No. Description

Section:

Series Qty

1 22003437 ASSY, AUGER & POST(ASPK-PRFP) 10 1

2 21001510 SCREW Note: SCREW, TUB 10 4

3 25-7953 SCREW Note: SCREW, TUB 10 6

4 25-7948 SCREW, AGITATOR RETENTION Note: BOLT, AGITATOR 10 1

5 35-3685 GASKET, BASKET TO CENTERPOST Note: GASKET, BASKET 10 1

6 35-3686 GASKET, TUB TO HOUSING Note: GASKET, TUB 10 1

7 25-7967 SCREW, SHOULDER Note: SCREW, BASKET 10 4

8 35-2328 SEAL, TUB TOP Note: SEAL, TUB TOP 10 1

9 21001905 DISPENSER, FABRIC (ONE PIECE) 10 1

10 21001529 BASKET ASSEMBLY (PLASTIC) 10 1

11 35-2978 SEAL, TUB/HOUSING 10 1

12 35-3700 TUB ASSEMBLY (PLASTIC) Note: TUB ASSEMBLY 10 1

13 21001531 TOP, TUB (PLASTIC) Note: TOP, TUB 10 1

14 21001530 BASE, AGITATOR 10 1

*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available
